Applicable Conditions
|
Water temperature
|
3-45℃
|
Inlet water pressure
|
0.1-0.6 MPa
|
Nominal micro rating
|
3-5μm
|
Material of Components
|
Carbon
|
high grade coconut shell carbon powder
|
End caps
|
PP
|
Sealing gasket
|
NBR or silicone rubber
|
Inner and outer Wraps
|
PP
|
Nettings
|
PE
|
Dimensions
|
End cap outer diameter (mm)
|
50/60/70
|
End cap inner diameter (mm)
|
16/28/28
|
Length (“)
|
9.75/10/20
|
Performance Diagram
Reduction of residual chlorine vs. Accumulated filtration volume

1.The above data are the results obtained by our laboratory.
2.Due to the difference in water quality and water consumption, the replacement cycle of the filter element will be different, depending on the actual use.
